Lack of experience in dealing with environmental conditions caused loss of position

A DP2 vessel with two redundant groups and operating in open bus mode, was involved in drilling operations in water depths of approximately 38 metres. The vessel was performing cone penetration testing (CPT) at a location with a drilling depth up to 90 metres. There were six thrusters and four generators available onboard and all were selected to DP. The available position reference systems (PRS) onboard were three DGNSS, one taut wire and one HPR, out of which only two DGNSS were selected to DP.

Also, out of the available four wind sensors, three of them were selected into DP, along with three gyros and three motion reference systems. The visibility was reported to be good with wind speed of fifteen knots at 045˚, current speed of four knots at 040˚and swells of two metres height with a duration of ten seconds at 220˚ were recorded during the operation. At the time of the incident, the vessel was drilling at a depth of 54 metres.

The vessel was encountering strong currents from the stern, as expected, and experienced by the DPO’s during the earlier spring tides. For this reason, the vessel receives location specific current modelling from a remote centre during its operations. These models display peak marine current’s direction and speed at any given time. During these strong currents, it is prudent to change the vessel heading regularly to follow the currents direction and to keep them at the stern.

At 20:00 hrs the senior DPO took over the watch at the DP desk and at 20:10 noticed the current was changing direction and intensity. The vessel heading was changed from 020˚ to 024˚ to keep the current at the stern. After the heading change, the loading on the vessel’s thrusters were observed to be within normal operating limits and the vessel maintained its position. At 20:45, the SDPO noticed another change in the direction and speed of the current, and further observed that the load was increasing on all thrusters. The drilling control was advised of the need to make a further heading change as the CPT operation was ongoing.

At 20:54 the DP consequence analysis advised that the load was higher than one of the two redundancy groups could tolerate post worst-case failure. Ten seconds later, power consumption was within limits again. The SDPO advised the drilling control of a further heading change which was confirmed at 20:56, and the heading was changed from 024˚ to 028˚. At 21:00 the DP consequence analysis warning indicated that the power online was in excess of the capacity of one redundant group, post worst-case failure. This alarm lasted for one and a half minutes. After completion of the heading change and at 21:05, the loading on the vessel’s thrusters were observed to be within normal operating limits and the vessel maintained its position. The SDPO handed over the watch to the DPO.

At 21:15 the DPO alerted the SDPO that the load on thrusters T3 and T4 were increasing. The SDPO, immediately attended the DP desk, noticing that thrusters T3 and T4 loads were increasing and that the vessel was struggling to maintain its position. At 21:19 the heading was changed by 2˚ to 030˚. At 21:21 the DP system indicated high loads on T3 and T4 followed by a consequence analysis “Off -Position” warning alarm. Simultaneously, there were speed feedback faults on both T3 and T4. At 21:22 a DP yellow alert was given to the drill operators as the vessel excursions overshot the ten percent of the water depth limitation.

The drillers immediately stopped their drilling operation, lifted the drilling equipment, and hoisted it back at the moonpool. The heading was changed to 040˚ where the current was at the vessel’s stern. At 21:25 the vessel settled down and could maintain position. At this time, the drilling assembly was inspected, and the pipe and the bottom hole assembly were observed to be in good condition. After a complete inspection, it was confirmed that there was no damage to the drilling equipment. Distance of uncontrolled movement during the event was nine metres and the duration of the event was recorded to be six minutes.

This case study demonstrates the importance of fully understanding the vessel's capability and normal operating limits, and also ensuring that this level of detail is clear within the ASOG. The case study also highlights the significance of training in emergency situations for key DP personnel.
